Introduction to API

Application programming interfaces, or APIs, simplify software development and innovation by enabling applications to exchange data and functionality easily and securely.

How an API works#

An API is a set of defined rules that explain how computers or applications communicate with one another. APIs sit between an application and the web server, acting as an intermediary layer that processes data transfer between systems.

Here’s how an API works:

1. A client application initiates an API call to retrieve information—also known as a request. This request is processed from an application to the web server via the API’s Uniform Resource Identifier (URI) and includes a request verb, headers, and sometimes, a request body.
2. After receiving a valid request, the API makes a call to the external program or web server.
3. The server sends a response to the API with the requested information.
4. The API transfers the data to the initial requesting application.

While the data transfer will differ depending on the web service being used, this process of requests and response all happens through an API. Whereas a user interface is designed for use by humans, APIs are designed for use by a computer or application.

APIs offer security by design because their position as middleman facilitates the abstraction of functionality between two systems—the API endpoint decouples the consuming application from the infrastructure providing the service. API calls usually include authorization credentials to reduce the risk of attacks on the server, and an API gateway can limit access to minimize security threats. Also, during the exchange, HTTP headers, cookies, or query string parameters provide additional security layers to the data.

For example, consider an API offered by a payment processing service. Customers can enter their card details on the frontend of an application for an ecommerce store. The payment processor doesn’t require access to the user’s bank account; the API creates a unique token for this transaction and includes it in the API call to the server. This ensures a higher level of security against potential hacking threats.

Types of APIs#

Nowadays, most application programming interfaces are web APIs that expose an application's data and functionality over the internet. Here are the four main types of web API:

• Open APIs are open source application programming interfaces you can access with the HTTP protocol. Also known as public APIs, they have defined API endpoints and request and response formats.
• Partner APIs are application programming interfaces exposed to or by strategic business partners. Typically, developers can access these APIs in self-service mode through a public API developer portal. Still, they will need to complete an onboarding process and get login credentials to access partner APIs.
• Internal APIs are application programming interfaces that remain hidden from external users. These private APIs aren't available for users outside of the company and are instead intended to improve productivity and communication across different internal development teams.
• Composite APIs combine multiple data or service APIs. These services allow developers to access several endpoints in a single call. Composite APIs are useful in microservices architecture where performing a single task may require information from several sources.

Types of API protocols#

As the use of web APIs has increased, certain protocols have been developed to provide users with a set of defined rules that specifies the accepted data types and commands. In effect, these API protocols facilitate standardized information exchange:

• SOAP (Simple Object Access Protocol) is an API protocol built with XML, enabling users to send and receive data through SMTP and HTTP. With SOAP APIs, it is easier to share information between apps or software components that are running in different environments or written in different languages.
• XML-RPC is a protocol that relies on a specific format of XML to transfer data, whereas SOAP uses a proprietary XML format. XML-RPC is older than SOAP, but much simpler, and relatively lightweight in that it uses minimum bandwidth.
• JSON-RPC is a protocol similar to XML-RPC, as they are both remote procedure calls (RPCs), but this one uses JSON instead of XML format to transfer data. Both protocols are simple. While calls may contain multiple parameters, they only expect one result.
• REST (Representational State Transfer) is a set of web API architecture principles, which means there are no official standards (unlike those with a protocol). To be a REST API (also known as a RESTful API), the interface must adhere to certain architectural constraints. It’s possible to build RESTful APIs with SOAP protocols, but the two standards are usually viewed as competing specifications.
• The WebSocket API is an advanced technology that makes it possible to open a two-way interactive communication session between the user's browser and a server. With this API, you can send messages to a server and receive event-driven responses without having to poll the server for a reply.

APIs, web services, and microservices#

A web service is a software component that can be accessed via a web address. Therefore, by definition, web services require a network. As a web service exposes an application’s data and functionality, in effect, every web service is an API. However, not every API is a web service.

Traditionally, API referred to an interface connected to an application that may have been created with any of the low-level programming languages, such as Javascript. The modern API adheres to REST principles and the JSON format and is typically built for HTTP, resulting in developer-friendly interfaces that are easily accessible and widely understood by applications written in Java, Ruby, Python, and many other languages.

When using APIs, there are two common architectural approaches—service-oriented architecture (SOA) and microservices architecture.

• SOA is a software design style where the features are split up and made available as separate services within a network. Typically, SOA is implemented with web services, making the functional building blocks accessible through standard communication protocols. Developers can build these services from scratch, but they usually create them by exposing functions from legacy systems as service interfaces.
• Microservices architecture is an alternative architectural style that divides an application into smaller, independent components. Applying the application as a collection of separate services makes it easier to test, maintain, and scale. This methodology has risen to prominence throughout the cloud computing age, enabling developers to work on one component independent of the others.

While SOA was a vital evolutionary step in application development, microservices architecture is built to scale, providing developers and enterprises with the agility and flexiblity they need to create, modify, test, and deploy applications at a granular level, with shorter iteration cycles and more efficient use of cloud computing resources.
